Re: A/c belt tensioner bracket bent/crooked?
Like This Post: - Subscribe to Daily Digest for this Bulletin Board
Posted by Rose Quartz 87 [Email] (#2119) [Profile/Gallery] (more from Rose Quartz 87) on Sun, 14 Apr 2024 12:29:16 Share Post by Email
In Reply to: Re: A/c belt tensioner bracket bent/crooked?, Rose Quartz 87 [Profile/Gallery] , Sun, 14 Apr 2024 11:42:51
Alert me when someone posts in this thread:
Members see ZERO ads on the bulletin boards and get more feature. - Help Keep This Site Online - Signup

What's also strange is then when I tighten the adjuster the bracket seems to pull away from the motor, I guess this is because the bolts holding the bracket to the motor are only on one side of the bracket.(I understand on later models a third attachment point was added, shared with the power steering belt tensioner bracket).

The picture is exaggerated, (pivot bolts loosened too much), to show what I mean. The red line shows what happens when the adjuster is tightened. When I tighten the bracket pivot bolts after the belt is tensioned, the pulley is straighter but remains a little crooked. The tension on the belt is correct once pivot bolts are tightened to 15 foot pounds, (M8 bolt).

Would belt length be more critical then with this setup?
