Relay 21A Posted by Cmyles [Email] (#1126) [Profile/Gallery] (more from Cmyles) on Tue, 11 Aug 2020 20:20:55 In Reply to: Re: Bad relay?, ThomasJ [Profile/Gallery] , Tue, 11 Aug 2020 14:42:27 Members do not see ads below this line. - Help Keep This Site Online - Signup |
Should be sockets for 6 relays and 10 fuses in that under seat fuse box. If you drew a birds-eye view of that fuse/relay box you would have a row of three relays at the top, then three more relays below that and then two rows of five fuses. The ignition switch relay 21A will be in the second row on the far left.
It's "F" in the attached photo and that relay energizes fuses 1,2,7,8,9 and 10 in that fuse box. So if you turn the key to run position and then pull that relay all of those fuses should go dead. I have hundreds of Bosch relays from C900's. I might have one for you.
